4-23
REASSEMBLY NOTE: When you reinstall the
shock absorbers in the base mounting brack-
ets, tighten the nut until it contacts the
bracket, then turn the nut an additional 1/4-
turn.
20. Remove the end of the vent tube from the
tub.
Excessive Weight Hazard
Use two or more people to move and
install washer.
Failure to do so can result in back or
other injury.
21. To remove the tub and basket:
a) Lift the tub and basket assembly and un-
hook the two suspension springs, then
remove the assembly from the washer,
and place it front-side down on a padded
surface.
REMOVING THE TUB ASSEMBLY (continued)
Suspension Spring
b) Remove the flat nuts from the tub.
Remove Flat Nuts
To Next Page
