WIKA operating instructions, model CEP6000
MM/YYYY country code based on 10/2014 GB/CN
GB
Input and
output signals
Measuring range Accuracy
(of reading)
Current signal
Output DC 0.000 ... 24.000 mA 0.015 % ±2 µA
Input DC 0.000 ... 24.000 mA (isolated)
DC 0.000 ... 24.000 mA (non-isolated)
0.015 % ±2 µA
0.015 % ±2 µA
Voltage signal
Output DC 0.000 ... 20.000 V 0.015 % ±2 mV
Input DC 0.000 ... 30.000 V (isolated)
DC 0.000 ... 20.000 V (non-isolated)
0.015 % ±2 mV
0.015 % ±2 mV
Resistance Stimulus current
Output 5.0 ... 400.0 Ω
5.0 ... 400.0 Ω
401 ... 1,500 Ω
1,501 ... 4,000 Ω
0.025 % ±0.1 Ω
0.025 % ±0.05 Ω
0.025 % ±0.5 Ω
0.025 % ±0.5 Ω
0.1 ... 0.5 mA
0.5 ... 3.0 mA
0.05 ... 0.8 mA
0.05 ... 0.4 mA
Input 0.00 ... 400.00 Ω
400.1 ... 4,000.0 Ω
0.025 % ±0.05 Ω
0.025 % ±0.5 Ω
Frequency
1)
Output 2.0 ... 600.0 CPM
2)
1.0 ... 1,000.0 Hz
1.0 ... 10.0 kHz
0.05 %
0.05 %
0.25 %
Input 2.0 ... 600.0 CPM
2)
1.0 ... 1,000.0 Hz
1.00 ... 10.00 kHz
0.05 % ±0.1 CPM
2)
0.05 % ±0.1 Hz
0.05 % ±0.01 kHz
Pulse
1)
Output 1 ... 30,000 counts
2.0 CPM
2)
... 10.0 kHz
Pressure
Input dependent on pressure module
1) Selectable amplitude of 1 ... 20 V based on a square wave
2) Counts per minute
10. Specifications
