WIKA operating instructions, model CEP6000
MM/YYYY country code based on 10/2014 GB/CN
GB
Input and output
signals
Measuring range Accuracy
(all errors incl.)
Thermocouple voltage
signals
-10.000 ... +75.000 mV 0.02 % of reading ± 10 µV
Thermocouples Without cold junction
compensation
With cold junction
compensation
3)
Type J -210.0 ... -150.0 °C
-149.9 ... +1,200.0 °C
0.4 °C
0.2 °C
0.6 °C
0.4 °C
Type K -200.0 ... -100.0 °C
-99.9 ... +600.0 °C
600.1 ... 1,000.0 °C
1,000.1 ... 1,372.0 °C
0.5 °C
0.2 °C
0.3 °C
0.4 °C
0.7 °C
0.4 °C
0.5 °C
0.6 °C
Type T -250.0 ... -200.0 °C
-199.9 ... 0.0 °C
0.1 ... 400.0 °C
1.5 °C
0.5 °C
0.2 °C
1.7 °C
0.7 °C
0.4 °C
Type E -250.0 ... -200.0 °C
-199.9 ... -100.0 °C
-99.9 ... +1,000.0 °C
1.0 °C
0.3 °C
0.2 °C
1.2 °C
0.5 °C
0.4 °C
Type R 0 ... 200 °C
201 ... 1,767 °C
1.7 °C
1.0 °C
1.9 °C
1.2 °C
Type S 0 ... 200 °C
201 ... 1,767 °C
1.7 °C
1.1 °C
1.9 °C
1.3 °C
Type B 600 ... 800 °C
801 ... 1,000 °C
1,001 ... 1,820 °C
1.5 °C
1.2 °C
1.0 °C
1.7 °C
1.4 °C
1.2 °C
Type C 0.0 ... 1,000.0 °C
1,000.1 ... 2,316.0 °C
0.5 °C
1.5 °C
0.7 °C
1.7 °C
Type XK -200.0 ... +800.0 °C 0.2 °C 0.4 °C
Type BP 0.0 ... 800.0 °C
800.1 ... 2,500.0 °C
1.9 °C
0.6 °C
2.1 °C
0.8 °C
Type L -200.0 ... +900.0 °C 0.2 °C 0.4 °C
Type U -200.0 ... 0.0 °C
0.1 ... 600.0 °C
0.4 °C
0.2 °C
0.6 °C
0.4 °C
Type N -200.0 ... -100.0 °C
-99.9 ... +1,300.0 °C
0.8 °C
0.3 °C
1.0 °C
0.5 °C
3) Error of cold junction compensation outside of 23 ± 5 °C is 0.05 °C/°C.
10. Specifications
