Windhager LogWIN Klassik - Page 63

12
2. For the Installer
LogWIN Klassik pellet ready:
for subsequent extension with a pellet boiler to the DuoWIN.
Fig. 7 LogWIN Klassik pellet ready – top view
1100
654
565
85
400
2028
2065
1289
All dimensions in mm:
LogWIN Klassik:
All dimensions in mm:
Minimum room heights: 1850 mm
Fig. 5 LogWIN Klassik exhaust pipe upwards – top view
498
883
1102
654 min. 550
min. 400
min. 700
min. 628 min. 200
min. 485
Fig. 6 LogWIN Klassik with exhaust pipe adapter– top view
498
883
1102
654 min. 550
min. 400
min. 700
min. 628 min. 200
min. 228
min. 485
