14
2. For the Installer
Note!
Do not screw the blower housing onto the adapter until the rear panel has been installed – otherwise
the rear panel cannot be installed.
– Secure adapter, with slot position depending on desired angle of flue connection, on boiler according to Fig. 12
with seal and 4 M8 nuts – Fig. 12, 13.
0°- 45°
45°- 90°
90°- 135°
135°- 180°
0°- 45°
45°- 90°
90°- 135°
135°- 180°
Fig. 12 Installation of adapter depending on angle of flue connection
Fig. 13 Adapter on the boilder (accessories)
Boiler side
Boiler side
Boiler side
Boiler side
