1128500 WPC 2000 User Manual
5-8 Troubleshooting
Problem: The Prior Act button on the Operator Station was depressed (i.e., switch was open)
after initiation of the stroke.
Remedy: Press Reset/Select. If the problem persists, check the wiring from the Operator
Station to WPC 2000. If necessary, Contact Wintriss Tech. Support.
Problem: The preset on the counter has been reached.
Remedy: Press Reset/Select to reset the counter to 1. The counter preset value remains the
same until you change it.
Problem: The Top Stop button on the Operator Station was depressed or the Top-stop circuit
was open after initiation of the stroke.
Remedy: Check other equipment (e.g. DiPro 1500, AutoSet, etc.) wired into the Top-stop
string. Correct the problem. Reset the other equipment first; then reset WPC 2000
and restart the press.
Problem: Cross-checked inputs 8 & 9 were in different states (i.e., open or closed) for longer
than 100 mS.
Remedy: Diagnose and correct the condition that the inputs are monitoring (see Table 5-2,
page 5-13).
Problem: Cross-checked inputs 10 & 11 were in different states (i.e., open or closed) for
longer than 100 mS.
Remedy: Diagnose and correct the condition that the inputs are monitoring (see Table 5-2,
page 5-13).
F14
F15
F16
F17
F18
