C-2 Option 1 User Inputs
Table C-1. Option 1 User Inputs: Input Type and Stop Type
User Input Number Input Type Stop Type
User input 12 NPN Top-stop
User input 13 NPN Top-stop
User input 14 NPN Top-stop
User input 15 NPN Top-stop
User input 16 NPN Top-stop
User input 17 NPN E-stop
User input 18 NPN E-stop
User input 19 NPN E-stop
User input 20 NPN E-stop
User input 21 NPN E-stop/Lockout
User input 22 PNP Top-stop
User input 23 PNP Top-stop
User input 24 PNP Top-stop
User input 25 PNP Top-stop
User input 26 PNP Top-stop
User input 27 PNP E-stop
User input 28 PNP E-stop
User input 29 PNP E-stop
User input 30 PNP E-stop/Lockout
User input 31 PNP E-stop
User input 32 (cross-checked with input 33) PNP E-stop
User input 33 (cross-checked with input 32) PNP E-stop
User input 34 (cross-checked with input 35) PNP E-stop
User input 35 (cross-checked with input 34) PNP E-stop
User input 36 (cross-checked with input 37) PNP E-stop/Lockout
User input 37 (cross-checked with input 36) PNP E-stop/Lockout
User input 38 (cross-checked with input 39) PNP E-stop/Lockout
User input 39 (cross-checked with input 38) PNP E-stop/Lockout
