WPC 2000 User Manual 1128500
Installation 2-13
If you are installing a light curtain, the Operator Station must be placed outside the area
guarded by the light curtain. You do not need to calculate a specific safety distance for your
Operator Station since the light curtain now prevents access to the pinch point. You must not,
however, mount the Operator Station between the light curtain and the pinch point.
Wiring a Pre-wired Operator Station
Checking Pre-wired Operator Station Wiring
Before connecting your pre-wired Operator Station to WPC 2000, check the wiring to the
mute lamp inside the Operator Station and modify, if necessary, according to the instructions
below. Operator stations shipped as part of WPC 2000 systems should not need modification.
1. Find the mute lamp on the Operator Station, as shown in Figure 2-6.
2. Open the Operator Station, and locate the mute lamp connections on the underside of the
cover.
Figure 2-6. Pre-wired Operator Stations Showing Mute Lamp Connections
MUTE
PALM
TIME
PRIOR
ACT
INTRISS
W
TOP
STOP
R
U
N
/
I
N
C
H
R
U
N
/
I
N
C
H
MUTE
PALM
TIME
PRIOR
ACT
INTRISS
W
TOP
STOP
Mute Lamp
Pre-wired
Operator Stations
top view
Side-button
Operator Station
Cover, opened,
showing underside
of cover.
(Top-button station
is similar.)
Mute Lamp Connections
for WPC 2000
E
M
E
R
G
E
N
C
Y
S
T
O
P
E
M
E
R
G
E
N
C
Y
S
T
O
P
