1128500 WPC 2000 User Manual
2-36 Installation
Mounting and Wiring the Cam Output Assembly
The cam output assembly can be ordered in an enclosure or as a PC board. To mount and wire
either option, do the following:
1. Select a convenient location for mounting the cam output assembly, choosing one that
allows you to easily run conduit from WPC 2000 to the cam outputs. You do not need to
access the cam outputs once they are installed and wired.
2. Mount the cam output assembly, referring to Figure 2-17 or Figure 2-18, page 2-37 for
mounting dimensions. Use the holes on the flanges to mount the cam output enclosure or
the corner holes to mount the cam output board.
3. The relays that will control your equipment should already be plugged into the cam output
board. If you need to replace a relay, simply pull the device out of its socket. Before
installing a relay, make sure that all the pins match the socket holes so you do not bend the
pins; then, press the relay in firmly.
4. Locate the twelve-conductor shielded cable that connects the WPC 2000 Main Processor
board to the cam outputs, and terminate the shield at each end near the entry point to the
enclosure or console (see Terminating Cable Shields, page 2-5).
5. Remove the TB109 connector from the WPC 2000 Main Processor board, and attach the
wires at one end of the cable to the terminals shown in Table 2-9, page 2-38 and Figure 6
at the end of the manual. Plug each connector back into its socket when you are finished.
BOARD DAMAGE OR SHORT CIRCUIT WHEN MOUNTED WITHOUT ENCLOSURE
• Mount the cam output assembly in a clean area where it will be safe from damage.
• Provide at least 0.5 in. (12.7 mm) clearance between the back of the board and any metal
surface.
Failure to comply with these instructions could result in property damage.
