2. PRODUCT PRESENTATION
2.1. List of included accessories
Check that all these accessories are included:
1 Power supply
1 Power cord
1 straight RJ45 cable (blue)
1 crossover RJ45 cable (yellow)
Breakout panels (as ordered)
SCSI Cables to connect to breakout panels
1 box including 1 CD-Rom and 1 quick start
2.2. Technical Specifications
The Relio is housed in a rugged 1U 19” rackmount enclosure. The Sealevel I/O boards interface to the CPU via
internal USB connections. Software drivers provide the capability to read the digital and analog I/O with a simple
process. The system is capable of using any or all of the following storage devices: Compact Flash, Microdrive, or
internal hard drive.
Processor Board
512 Gb DDR RAM installed; Max. capacity 1 Gb
10/100BaseT Ethernet
One RS-232 serial port
VGA video output
Four USB 2.0 ports
Internal USB for interface to I/O boards
Additional I/O Designed into Custom I/O Board
10/100BaseT Ethernet with RJ45 connector
Four software selectable RS-232/422/485 ports on high density connector
Data Storage
One CompactFlash card for system files
One 2.5” hard disk drive for user data
