Hardware Specifications
Digital Inputs 64 OPTO non-polarized inputs 5 – 30 V, input resistance 6.2 kΩ
Digital Outputs 64 Open Collector Outputs 0 – 30 V @ 250 mA
A/D Channels 24 multiplexed 16 bit differential inputs
Range +/– 10 V
Impedance 2 GΩ
Protection fault protected for overvoltages of +/– 30 V with power on or off
Front Panel
 2 Status LEDs
o Power – not under software control, power indication only
o Maintenance mode – under software control
 Maintenance push button Switch
o Toggles Maintenance mode on/off
Rear Panel
 12 V +/– 5% Regulated Power input connector
 One stereo audio output jack
 One stereo audio input jack
 DB-15 VGA connector
 Four DB-9 Serial ports that support RS232/422/485
 One DB-9 Serial port that supports RS232
 Two RJ45 10/100 Ethernet ports
 One RJ11 Phone port for Voice/Data modem
 Four USB 2.0 ports
 Two 68pin SCSI connectors with a total of 64 – OPTO inputs
 Two 68pin SCSI connectors with a total of 64 – Open Drain outputs
 One 50pin SCSI connector with 24 - A/D inputs
 Removable screw terminal for remote reset connection
Disk Drives
 One internal compact flash card
 One internal 2.5” hard drive
Input Power - 12 V +/– 5% @ 5 A
Pinouts of the I/O SCSI connectors are available in Appendix A
