Figure 1-23 Figure 1-24

2．Tools used for chassis overhaul

Common and special tools, as well as their pictures for chassis component assembly and disassembly are listed in

Table 1-25 and Table 1-26.

Table 1-25

Name Remarks

Torque wrench

Allen wrench

Socket wrench

Micrometer

Magnetic stand, V-block

Dial gauge

Vernier caliper

Spring clamp ring pliers

Hammer screwdriver

Front fork oil seal installer

Front fork seal driver

Steering nut wrench

Figure 1-27

Figure 1-28

Figure 1-29

Figure 1-30

Figure 1-31

Figure 1-32

Figure 1-33

Figure 1-34

Figure 1-35

Figure 1-36

Figure 1-37

Figure 1-38

（1）General tools used for chassis overhaul

Continued Table 1-26

Figure 1-27 Figure 1-28

Figure 1-29 Figure 1-30
