7.5 Front Fork
7.5.1 Removal
Support the motorcycle with the middle stand.
Remove front wheel.
Remove brake caliper and brake pipe clip.
Remove front mudguard（1） and reflector（2）.
Remove the handle.
Screw off upper bracket mounting bolt and lower bracket pinch bolt.
Remove headlamp bracket.
Remove the front fork.
Tools:
Steering handle welded assembly mounting bolt wrench
Locknut wrench
Special remover for bearing steel bowl
* Attention:
Clean the opening part of protecting plate of motorcycle block with a cloth.
Upper and lower bearing steel bowls shall be removed with special bearing steel bowl remover.
