4.5 Tail Lamp Bulb Replacement
4.5.1 Removal
Screw off the two bolts（1）.
Remove the tail lamp hood.
Disconnect wire connector to the tail lamp.
While pressing down the tail lamp, rotate it counterclockwise
Remove the tail lamp
4.5.2 Installation
Install the tail lamp in the reverse order of removal.
* Attention
While installing tail lamp, be sure that sealing washer on the
tail lamp hood is in good condition and correct position.
4.5.3 Tail lamp bulb replacement
4.5.3.1 Removal
Screw off mounting bolts on the tail lamp hood.
Remove tail lamp hood（3）so that tail lamp bulb can be removed.
Remove the tail lamp bulb from lamp adapter（2）.
4.5.3.2 Installation
Install the tail lamp bulb in the reverse order of removal
4.6 Instrument
Remove rear mirror.
Take down the handle hood and pull out waterproof connector.
Remove the screw.
Remove odometer assembly.
Remove the instrument.
Install the instrument orderly in the reverse order of removal.
