4.7 Ignition Switch and Steering Lock
4.7.1 Inspection
Remove the headlamp from the cover.
Remove ignition switch-wire connector.
“ ” (OFF) position：All the circuits are broken.
“
” (ON）position：Ignition circuit is switched on and engine can be
started. When the switch is at this position, the key cannot be pulled out.
“
”(Stop) position：At night, when you have to stop the motorcycle at
roadside, turn the key to“
”position and you will be able to pull out the
key and the tail lamp (Stop Lamp) will be kept on.
4.7.2 Ignition switch replacement
Remove the headlamp.
Screw off the mounting bolts and remove the ignition switch holder.
Remove the mounting bolts and replace ignition switch.
4.8 Electric Horn
Inspection
Disconnect wire to the electric horn.
Connect lead wire of horn with the battery. When the electric horn
sounds, it indicates the horn is in good condition.
4.9 Handle Switch
Remove protecting plate of steering handle.
Screw off mounting bolt on the brake lever and take down the bracket.
