IX Fuel Tank/Seat Cushion
Preparatory data----------------------9.1
Fault diagnosis-------------------9.2
Fuel tank/seat cushion-----------9.3
9.1 Preparatory Data
Precautions on Operation
Working site for removal shall be away from fire source.
Fuel switch shall be set at “OFF” position while removing fuel tank.
While installation, tighten bolt and nut to their specified torque.
After installation, check if all the components are correctly fixed and work normally.
Basic data
Item Standard Service limit
Fuel tank capacity 16 16.5
Tightening torque
Cushion mounting bolt 22-29 N·m
Fuel tank mounting bolt 5 - 9 N·m
9.2 Fault Diagnosis
Reducing Fuel Level
Natural consumption
Oil leakage
To Next Page
