Wulfsberg C-5000 User Manual

Page 5-10 Publication No. 150-041118
Section 5 – Configuration and Programming Rev. A
Sep 2001
1 ..M 156.200
2
φ
φφ
φ
..1 TACTICAL-001
The manual channel’s frequency is displayed in place of the alphanumeric identifier for preset channels. Once the
manual channel is selected, press the EDIT button to edit the channel information. The C-5000 automatically stores
the manual channel information on power down.
Using the Direct/Repeat Feature
The C-5000 supports both direct and repeat modes of operation. Any preset channel that has identical transmit and
receive frequencies is considered a direct channel. If the transmit and receive frequencies are different, the C-5000
considers the channel a repeater channel. Repeater channels can be temporarily changed into direct channels by
pressing the DIR button. This will temporarily copy the receive frequency into the transmit frequency. The direct
mode indicator will light. The following illustration shows radio 1 in direct mode.
1 123
→
→→
→
LUKEAFB TWR1
2
φ
φφ
φ
..1 TACTICAL-001
Pressing the DIR button on a direct channel has no effect.
Receiving/Transmitting
Receiving
The C-5000 is constantly monitoring its radios for reception. When a signal is received, the C-5000 will light the
receive indicator for the receiving radio, and route the audio to the operator’s headset (Assuming the associated
intercom switch is selected). The following illustration depicts Radio #1 receiving.
1 123
→
→→
→
LUKEAFB TWR1
2
φ
φφ
φ
..1 TACTICAL-001
Transmitting
To transmit on a radio system, select the appropriate source on your audio panel, and key the microphone.
Transmission will begin on the radio’s currently selected channel. During the transmission, the radio’s transmit
indicator will light, and the channel’s transmit frequency will be displayed. The following illustration depicts radio
1 transmitting.
RX Indicator
Direct Mode Indicator
NOTE:
