Wulfsberg C-5000 User Manual

C-5000 COMMUNICATION MANAGEMENT CONTROLLER
INSTALLATION MANUAL
Publication No. 150-041118 Page 5-17
Rev. A Section 5 – Configuration and Programming
Sep 2001
..1 506.987R T.17 FM
S H 509.987T T.17 ..
• Rotate the VALUE knob clockwise once. The modulation indicator will toggle between AM and FM. (118-
136 MHz and 225-400 MHz are normally AM frequencies. All other frequencies are usually FM)
Changing Receiver Bandwidth
The receiver bandwidth can only be changed on the manual channel. To change the manual channel’s receiver
bandwidth, do the following.
• Move the cursor under the bandwidth field, as depicted below.
..1 506.987R T.17 FM
S H 509.987T T.17 ..
• Rotate the VALUE knob in either direction. Each turn of the VALUE knob will select the next bandwidth
option in the list. Turn the VALUE knob until the desired bandwidth symbol is displayed. The available
options are as follows.
N – Narrow – 12.5 kHz
S – Standard - 25 kHz
W – Wide – 35 kHz
X – Extra Wide – 70 kHz
UNLESS SPECIFICALLY INSTRUCTED OTHERWISE, ALWAYS SELECT “S”.
