Wulfsberg C-5000 User Manual

C-5000 COMMUNICATION MANAGEMENT CONTROLLER
INSTALLATION MANUAL
Publication No. 150-041118 Page 5-61
Rev. A Section 5 – Configuration and Programming
Sep 2001
Appendix A – CTCSS (PL) Tone Codes
C-5000
TONE
CODE
TONE
FREQ (HZ)
EIA
TONE
CODE
C-5000
TONE
CODE
TONE
FREQ (HZ)
EIA
TONE
CODE
01 67.0 XZ
35 179.9 6B
02 71.9 XA 36 186.2 7Z
03 74.4 WA 37 192.8 7A
04 77.0 XB 38 203.5 M1
05 79.7 SP 39 N/A N/A
06 82.5 YZ 40 N/A N/A
07 85.4 YA 41 210.7
08 88.5 YB 42 218.1
09 N/A N/A 43 225.7
10 N/A N/A 44 233.6
11 91.5 ZZ 45 241.8
12 94.8 ZA 46 250.3
13 97.4 ZB 47 229.1
14 100.0 1Z 48 150.0
15 103.5 1A 49 N/A N/A
16 107.2 1B 50 N/A N/A
17 110.9 2Z 51 69.4
18 114.8 2A 52 159.8
19 N/A N/A 53 165.5
20 N/A N/A 54 171.3
21 118.8 2B 55 177.3
22 123.0 3Z 56 183.5
23 127.3 3A 57 189.9
24 131.8 3B 58 196.6
25 136.5 4Z 59 N/A N/A
26 141.3 4A 60 N/A N/A
27 146.2 4B 61 199.5
28 151.4 5Z 62 206.5
29 N/A N/A 63 254.1
30 N/A N/A 64 Reserved
31 156.7 5A 65 Reserved
32 162.2 5B
66 Reserved
33 167.9 6Z 67 Reserved
34 173.8 6A 68 Reserved
