Page 5-50 Publication No. 150-041118
Section 5 – Configuration and Programming Rev. A
Sep 2001
to allow the integration to function correctly. Further definition of each entry may be obtained by pressing F1 with
the entry highlighted on screen. Settings should be as follows:
Text Justification – LEFT Alt Display Time - 1000
Channel Size – 9 Temp Msg Display Time - 1000
Zone Text Size – 3 Display Light Time - 5
Slow Scroll Delay – 1000 Auto Light - DISABLED
Fast Scroll Delay – 250 Emergency Receive - DISABLED
Slow Scroll Count – 3 Display SYS/SUB - DISABLED
Talkgroup Radio Lock - DISABLED
Display on Mode Change – DISABLED
Display on Receive – DISABLED
Display on PTT – DISABLED
CONVENTIONAL MENU – Displayed by pressing F4 ! F6 from the Main Menu. This is the primary submenu
leading to all aspects of programming for Conventional type channels, whether they are Analog or Digital
(ASTRO). The following paragraphs detail the screens accessible from this menu.
CONVENTIONAL RADIO WIDE OPTIONS – Displayed by pressing F4 ! F6! F2 from the Main Menu.
This page contains settings that affect all Conventional channels throughout the radio. Two key settings here are the
Monitor Type and Latch Enable Timer. They MUST be set to Open Squelch and Disabled respectively for the TEST
feature to function properly on the C-5000 control head. Other settings should remain as listed below:
Monitor Type – OPEN SQUELCH
Latch Enable Tone – ENABLED
Latch Enable Timer – DISABLED
Smart PTT Retry Timer – 275
Smart PTT Quick Key Timer – 500
Hub Defeats PL – DISABLED
Direct Frequency Enabled - DISABLED
Personality Programming (Conventional Analog FM Personalities)
CONVENTIONAL PERSONALITY – Displayed by pressing F4 ! F6 ! F3 from the Main Menu. All the
aspects of any given channel are assigned to a personality numbered 1 through 255. The following three sections
will show similar screen shots for each example mentioned above.
Personality Number – This is the sequential number of all personalities programmed into the radio. There are 255
personalities available.
Receive Only – This makes the personality a RECEIVE ONLY channel. This is useful for channels like National
Weather and ATIS frequencies. Normally this will be DISABLED except on those special channels mentioned
above.
Direct / Talkaround – This selection is ONLY available if a pair of frequencies is entered below signifying that this
is a repeater frequency. It controls whether or not this personality may be placed into DIRECT or Talkaround mode.
Since the C-5000 is capable of actuating this feature, ALL repeater personalities should have this feature
ENABLED.
Time Out Timer – There are 4 available Transmit Time-Out Timers – when transmitting continuously beyond the
time specified, the transmit function stops and the user hears a bonk in the speaker. Leave this set to 1-INFINITE.
