SYSTEM SETUP MODE
HOME=EXIT 2=REVIEW
• Press the HOME button to exit system configuration, or the MODE button to review current settings.
Configuring the C-5000 to Control an RT-5000
This section drills down into the radio setup sub-menu pages. Refer to the section on configuring the C-5000 for
details on how to reach these menu pages. This section assumes the C-5000 part number you entered indicated an
RT-5000 was present for Radio #1. We pick up at the following display page.
SETUP: 2=NEXT 3=BACK
ENTER=SETUP RADIO #1
• Press the ENTER button to begin configuring the RT-5000.
SYS #1:2=NEXT 3=BACK
RT-5000 P/N = 0703
• Use the cursor/value knobs to input the last four digits of your RT-5000’s part number. Press the MODE button
to display the next menu page.
SYS #1:2=NEXT 3=BACK
ENTER=SETUP GUARD #1
• This page will only display if RT-5000 part number entered indicates a Guard receiver is present. Pressing the
ENTER button invokes the preset channel programming menu pages for the Guard channel. Refer to the
section on programming a preset channel for details since programming a Guard channel is very similar to
programming a preset channel.
SYS #1:2=NEXT 3=BACK
RADIO MODE = 1
• This page will only display if RT-5000 part number entered indicates an ITM is present. Use the cursor/value
knobs to select a value of 1 or 2. Mode 1 indicates that the ITM should act as part of the main transceiver, i.e.
the two transceivers appear to be a single unit. Mode 2 indicates that the ITM should not act as part of the
main, i.e. behave as a Guard receiver. . Press the MODE button to display the next menu page.
