Supplies
Xerox
®
B205 Multifunction Printer
User Guide
178
Replacing the Drum Cartridge
1. Open the front cover.
2. Pull the toner cartridge out and place it on a clean flat
surface.
3. Pull the drum cartridge out slowly.
4. Remove the new drum cartridge from the packaging. Follow directions on the packaging to
remove the tape and appropriate packaging pieces from the new cartridge. Use the handle on the
cartridge to avoid touching sensitive parts that can be easily damaged.
CAUTIONS:
• To prevent damage to the drum cartridge, do not expose it to light for more than a few
minutes. Cover it with a piece of paper, if necessary.
• Do not touch the green surface on the underside of the cartridge. Use the handle on the
cartridge to avoid touching this area.
5. Hold the drum cartridge by the handle and insert it into
the printer until it locks into place.
6. Re-install the toner cartridge.
7. Close the front cover. Make sure that the door is securely
closed. When the green system status light is solid, the
printer is ready.
Recycling Supplies
For information on Xerox supplies recycling programs, go to www.xerox.com/gwa.
