Parts of the Printer
Xerox
®
B205 Multifunction Printer
User Guide
27
Control Panel Overview
The control panel consists of a display, and buttons you press to control the functions available on the
printer. The control panel:
• Displays the current operating status of the printer.
• Provides access to copy, print, and scan.
• Provides access to information pages.
• Prompts you to load paper, replace supplies, and clear jams.
• Displays errors and warnings.
.
1 2
3
4
5
7
8
6
13
12
9101114
Number Button Description
1 Copy: Activates Copy mode.
2 Scan: Activates Scan mode. Provides access to Scan to Network, Scan to
PC, Scan to Email and Scan to USB options.
3 Display Screen: Displays all the available programming features, plus
general printer information.
4 Machine Status: Use this button to access the System Menus to view
printer status information and the printer serial number, and to update
printer settings.
