TCP/IP (LPD or Port9100) Installation
Xerox CopyCentre/WorkCentre 118 System Administration Guide 73
Network Communication Setup
Enable the following ports using the control panel or CentreWare Internet Services.
• Printing through LPD: LPD port
• Printing through Port9100: Port9100 port
Set the IP address using the control panel.
NOTE: CentreWare Internet Services allows more detailed settings. Refer to
CentreWare Internet Services chapter on page 91.
Workstation Setup
This requires the workstations in the networking environment to be configured to
communicate with the machine.
Test Print
A print job should be submitted to make sure that the machine has been installed and
configured correctly.
Network Communication Setup
This section describes how to set up the network communication parameters of the
machine.
At the machine, perform these steps.
NOTE: Keep the SNMP port enabled while you use the machine on the TCP/IP
network.
NOTE: CentreWare Internet Services can also be used to configure the machine.
Refer to CentreWare Internet Services chapter on page 91.
First, enable the [LPD] or [Port9100] port.
1. Connect the machine to the network.
2. Press the <Log In/Out> button.
3. Select [System Settings].
4. Enter the password using the numeric keypad and then select [Confirm].
5. Select [Print Settings] and then press the <Enter> button.
6. Press the <Enter> button on the [Network/Port] screen.
7. Select [LPD] or [Port9100] by selecting [T] or [S] and then press the <Enter>
button.
8. Select [Port Status] by selecting [T] or [S] and then press the <Enter> button.
9. Select [Enable] by selecting [T] or [S] and then press the <Enter> button.
To Next Page
