Xerox DocuPrint C1190 FS User Manual

Paper Jams
10-8
3. Hold the fuser cover as shown in the figure and open the cover. Then, remove the jammed paper.
4. Place the green levers on both sides of the fuser unit to their original positions.
5. Close the front cover.
Caution: When closing the front cover, be careful not to get your fingers caught between (the left,
right, top, or bottom edge of) the cover and the printer.

Xerox DocuPrint C1190 FS Specifications

General

Brand	Xerox
Model	DocuPrint C1190 FS
Category	All in One Printer
Language	English
