Xerox Phaser 3320DN

Control Panel Overview
Xerox Phaser 3320DN/3320DNI
System Administrator Guide
10
Control Panel Overview
Display Screen: Displays the current machine status
and prompts during an operation.
Arrows: The up/down and left/right arrows are used to
scroll through the options available in the selected
menu, and to increase or decrease values.
OK: Confirms the selection on the screen.
Menu: Enters Menu Mode and enables you to access
options and settings.
Back: Used to go back one level in the menu.
Power Save: Sends the machine into Power Save
mode or Power Down. Press the button again to restart
the machine.
Stop: Pressing the Stop button stops an operation at
any time.
Status / Wireless LED: The color of the LEDs indicates
the machine’s current status. For more information
refer to the User Guide supplied with your machine.
Note: The Wireless LED applies to the Phaser
3320DNI only.
1
2
3
4 5
6 7
8
1
2
3
4
5
6
7
8
