Xerox Phaser 3320DN System Administrator Guide

Machine Parts and Connection Ports
Xerox Phaser 3320DN/3320DNI
System Administrator Guide
13
Rear View
Initial Connection
The On/Off switch, the power outlet and the Network Port are at the rear of the machine. Follow these
steps to physically connect your machine to the network:
1. Connect the Power Cord to the machine and a suitable power supply outlet. The power cord must
be plugged into a grounded power socket.
2. Connect the Network Cable if required. The Phaser 3320DNI will also connect to a wireless
network, if available, when powered on.
Note: If you choose a wireless connection for your Phaser 3320DNI printer, you cannot use a
wired connection at the same time.
Network Port Duplex Unit
USB Port Rear Door
Power Switch Paper Tray Rear Cover
Power Receptacle
1
2
3
4
5 6
7
1
5
2
6
3
7
4
