Xerox Phaser 3635MFP User Manual

6-34
Phaser 3635MFP
dC131
Draft 4
General Procedures and Information
NOTE: If the NVM default characters exceed 10 characters only the first eight characters are
displayed in the list. The full string is displayed in the Read/Write window.
NOTE: Selecting Reset will cause the selected NVM location to be reset to its default value.
Selecting Cancel closes the window and cancels any changes made in the now closed win-
dow.
NOTE: The CSE cannot read or modify any NVM that contains customer administrative or
accounting data.
NOTE: The Read Only (protected) NVM can only be changed using a password obtained from
Xerox.
Table 1 NVM chain 6
Location NVM Name NVM Description Value Default
06-100 Vertical Magni-
tude
The changed dimension of the
vertical direction magnitude.
0mm to 6mm
(12 steps /
0.5mm seg.)
3
06-110 Horizontal Magni-
tude
The changed dimension of the
horizontal direction magnitude.
0mm to 6mm
(12 steps /
0.5mm seg.)
3
Table 2 NVM chain 7
Location NVM Name NVM Description Value Default
07-100 Top Registration
Tray 1 Simplex
The changed dimension of tray
1 top registration in simplex.
0mm to 6mm
(12 steps /
0.5mm seg.)
3
07-110 Side Registration
Tray 1 Simplex
The changed dimension of tray
1 side registration in simplex.
0mm to 6mm
(12 steps /
0.5mm seg.)
3
07-120 Top Registration
Tray 1 Dup_long
(2nd side)
The changed dimension of tray
1 top registration of 2nd side in
duplex long.
0mm to 6mm
(12 steps /
0.5mm seg.)
3
07-130 Side Registration
Tray 1 Dup_long
(2nd side)
The changed dimension of tray
1 side registration of 2nd side
in duplex long.
0mm to 6mm
(12 steps /
0.5mm seg.)
3
07-140 Top Registration
Tray 1 Duplex
(1st side)
The changed dimension of tray
1 top registration of 1st side in
duplex long and short.
0mm to 6mm
(12 steps /
0.5mm seg.)
3
07-150 Side Registration
Tray 1 Duplex
(1st side)
The changed dimension of tray
1 side registration of 1st side in
duplex long and short.
0mm to 6mm
(12 steps /
0.5mm seg.)
3
07-200 Top Registration
Tray 2 Simplex
The changed dimension of tray
2 top registration in simplex.
0mm to 6mm
(12 steps /
0.5mm seg.)
3
07-210 Side Registration
Tray 2 Simplex
The changed dimension of tray
2 side registration in simplex.
0mm to 6mm
(12 steps /
0.5mm seg.)
3
07-220 Top Registration
Tray 2 Dup_long
(2nd side)
The changed dimension of tray
2 top registration of 2nd side in
duplex long.
0mm to 6mm
(12 steps /
0.5mm seg.)
3
07-230 Side Registration
Tray 2 Dup_long
(2nd side)
The changed dimension of tray
2 side registration of 2nd side
in duplex long.
0mm to 6mm
(12 steps /
0.5mm seg.)
3
07-240 Top Registration
Tray 2 Duplex
(1st side)
The changed dimension of tray
2 top registration of 1st side in
duplex long and short.
0mm to 6mm
(12 steps /
0.5mm seg.)
3
07-250 Side Registration
Tray 2 Duplex
(1st side)
The changed dimension of tray
2 side registration of 1st side in
duplex long and short.
0mm to 6mm
(12 steps /
0.5mm seg.)
3
07-500 Top Registration
Bypass Simplex
The changed dimension of
bypass top registration in sim-
plex.
0mm to 6mm
(12 steps /
0.5mm seg.)
3
07-510 Side Registration
Bypass Simplex
The changed dimension of
bypass side registration in sim-
plex.
0mm to 6mm
(12 steps /
0.5mm seg.)
3
07-520 Top Registration
Bypass Dup_long
(2nd side)
The changed dimension of
bypass top registration of 2nd
side in duplex long.
0mm to 6mm
(12 steps /
0.5mm seg.)
3
07-530 Side Registration
Bypass Dup_long
(2nd side)
The changed dimension of
bypass side registration of 2nd
side in duplex long.
0mm to 6mm
(12 steps /
0.5mm seg.)
3
07-540 Top Registration
Bypass Duplex
(1st side)
The changed dimension of
bypass top registration of 1st
side in duplex long and short.
0mm to 6mm
(12 steps /
0.5mm seg.)
3
07-550 Side Registration
Bypass Duplex
(1st side)
The changed dimension of
bypass side registration of 1st
side in duplex long and short.
0mm to 6mm
(12 steps /
0.5mm seg.)
3
Table 3 NVM chain 9
Location NVM Name NVM Description Value Default
09-100 LD Light Level 600dpi laser light level. Value
in PWM.
200 to 600 350
09-110 MHV Control Bias
Control
Main charge bias control.
Basic of value (HVPS setting is
value). Value in PWM.
108 to 145 126
09-120 THV Bias Control
Control
Transfer bias control. Basic of
value (HVPS setting is value).
Value in PWM.
41 to 220 76
09-130 Deve Bias Control DEVE bias control. Basic of
value (HVPS setting is value).
Value in PWM standard volt-
age: --500V (PWM 522).
408 to 607 522
Table 2 NVM chain 7
Location NVM Name NVM Description Value Default

Xerox Phaser 3635MFP Specifications

General

Network ready	Yes
Dimensions (WxDxH)	472 x 478 x 54 mm
Networking features	Fast Ethernet
All-in-one functions	Copy, Fax, Print, Scan
Color all-in-one functions	Scan
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	33 ppm
Digital sender	No
Maximum duty cycle	75000 pages per month
Page description languages	PCL 5e, PCL 6, PostScript 3
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	99 copies
Scan to	E-mail, Fax, FTP, USB
Maximum scan area	220 x 300 mm
Image formats supported	JPG, TIF
Faxing	Mono faxing
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, JPEG, MH, MMR (Fax coding method), MR
Fax speed dialing (max numbers)	199
Paper input type	Paper tray
Total input capacity	550 sheets
Total output capacity	250 sheets
Maximum number of input trays	3
Auto document feeder (ADF) input capacity	60 sheets
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
ISO A-series sizes (A0...A9)	A4, A5
Maximum ISO A-series paper size	A4
Display	LCD
Market positioning	Business
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	1
Security algorithms	802.1x RADIUS, HTTPS
Supported network protocols (IPv4)	FTP, HTTP, HTTPs, LPR, SNMPv1, SNMPv2, SNMPv3, TCP/IP, UDP
Internal memory	512 MB
Card reader integrated	-
Internal storage capacity	80 GB
Sound pressure level (printing)	59 dB
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	15 W
Power consumption (PowerSave)	55 W
Power consumption (average operating)	600 W
Mac operating systems supported	Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Windows operating systems supported	Windows 2000, Windows 2000 Professional, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Professional, Windows XP Professional x64
Storage temperature (T-T)	10 - 32 °C
Operating temperature (T-T)	16 - 30 °C
Storage relative humidity (H-H)	20 - 80 %
Operating relative humidity (H-H)	30 - 70 %
Sustainability certificates	ENERGY STAR
Certification	CE, FCC, RoHS
