Features
Item
Name Description
1
Button
This button displays the status of the printer on the touch screen.
2 Job Status Button This button displays lists of all active, secure, or completed jobs on the touch screen.
3 Services Button
This button returns to the active service from the Job Status or Machine Status screens, or
to a preset service.
4 USB Port
The port provides USB Flash drive connection for storage use for the Scan to USB and
Print from USB functions.
5
Button
This button provides access to printer features, such as copy, scan, and fax, on the touch
screen.
6
Touch Screen
Display
The screen displays information, and provides access to printer functions.
7 Log In/Out Button This button provides access to password-protected features.
8 Help Button This button displays information about the current selection on the touch screen.
9 Language Button This button changes the touch screen language and keyboard settings.
10 Energy Saver Button This button enters and exits the low-power mode.
11 Interrupt Button This button pauses the current job to run a more urgent print, copy, or fax job.
12 Clear All Button
This button clears previous and changed settings for the current selection. To
reset all features to their default settings and clear existing scans, press this
button twice.
13 Stop Button
This button stops the current job temporarily. To cancel or resume your job, follow the
onscreen instructions.
14 Start Button This button starts the selected copy, scan, fax, or Print From job, such as Print from USB.
15
Keypad
The keypad enters alphanumeric information.
16 C (clear) Button This button deletes numeric values or the last digit entered using the alphanumeric keys.
This button inserts a pause in a telephone number when it transmits a fax.
Xerox
®
WorkCentre
®
7970 Multifunction Printer 27
User Guide
