Xilinx MultiLINX Series User Manual

Hardware User Guide
1-10 Xilinx Development System
Figure 1-4 Parallel Cable III and FPGA Flying Leads
The following figure shows top and bottom views of the Parallel
Cable III, including the FPGA and JTAG (CPLD) headers.
PROG
GND
FPGA Flying Lead Connector
Connections to
Target System
DB25 Plug Connector
Parallel Cable III
X8325
FPGA VCC
CCLK
D/P
DIN
