Hardware User Guide
2-10 Xilinx Development System
can remain powered up and does not get powered down when the
circuit board power is off.
Device Configuration Modes
The various MultiLINX device configuration modes supported for
each device are shown in the following table.
Downloading Configuration Data
This section details the connections needed to download configura-
tion data with the MultiLINX Cable.
Slave Serial Mode (XC3000)
The following figure shows in detail the Slave Serial Mode connec-
tions to a XC3000 device for Downloading Configuration Data.
Table 2-3 MultiLINX Device Configuration Modes
Configuration
Mode
Device
Virtex Spartan XC9500 XC5200 XC4000 XC3000
SelectMAP X
SlaveSerialXXXX
JTAGXXXXX
