Hardware User Guide

3-4 Xilinx Development System

• A prototype area on the PC board

Figure 3-1 FPGA Demonstration Board Displays

General Components

Thissectiondescribesthecommoncomponentsthatarefoundonthe

FPGA Demonstration Board. The following figure shows the compo-

nent layout of the FPGA Demonstration Board.

U6 U7 U8

XC3000

XC4000

X4710

XC3000

XC4000

7-Segment Display

Bars
