Xilinx MultiLINX Series User Manual

MutliLINX
™
Cable
Hardware User Guide 2-11
Figure 2-3 Slave Serial Mode (XC3000)
Slave Serial Mode (Virtex, Spartan, XC5200, XC4000)
The following figure shows in detail the Slave Serial Mode connec-
tions for Virtex, Spartan, XC5200, and XC4000 devices.
D0
D1
D2
D3
D4
D5
D6
D7
RDY/BUSY
CS2
CS1
CS0 (CS)
WS
GND
CCLK
DIN
RT
TDI
TCK
TMS
RST
TRIG
RD (TDO)
PWR
VCC
RS (RDWR)
CLK2-IN
CLK2-OUT
CLK1-IN
CLK1-OUT
DONE (D / P)
PROG
INIT
4
2
3
1
NOTE: Pull-up resistors are 4.7k ohm.
VCC
Circuit Board
XILINX device
MultiLINX Connectors
M0 M1 M2
INIT
CCLK
RESETPWRDN
DIN
D/P
VCC
VCC
VCCVCCVCC
VCC
X8942
