Hardware User Guide
1-16 Xilinx Development System
Figure 1-9 XChecker Cable and Flying Leads
The following figure shows top and bottom views of the XChecker
Cable.
Connection to Host Computer
XChecker Cable
Flying Lead Connector 1
Header 1
Header 2
Flying Lead Connector 2
DB25 Adapter DB9 Socket Connector
+5V
Test Fixture
(Enlarged to
show plugs)
Connections to
Target System
Connections to
Target System
GND
X8322
VCC
GND
CCLK
D/P
DIN
PROG
INIT
RST
TRIG
RD
RT
TDI
TCK
TMS
CLK1
CLK0
