Xilinx VC709 User Manual

18 www.xilinx.com VC709 Evaluation Board
UG887 (v1.0) February 4, 2013
Chapter 1: VC709 Evaluation Board Features
AP11 DDR3_B_D59 193 DQ59
AM13 DDR3_B_D60 180 DQ60
AN13 DDR3_B_D61 182 DQ61
AM11 DDR3_B_D62 192 DQ62
AN11 DDR3_B_D63 194 DQ63
AT22 DDR3_B_DM0 11 DM0
AL22 DDR3_B_DM1 28 DM1
AU24 DDR3_B_DM2 46 DM2
BB23 DDR3_B_DM3 63 DM3
BB12 DDR3_B_DM4 136 DM4
AV15 DDR3_B_DM5 153 DM5
AK12 DDR3_B_DM6 170 DM6
AP13 DDR3_B_DM7 187 DM7
AP22 DDR3_B_DQS0_N 10 DQS0_N
AP23 DDR3_B_DQS0_P 12 DQS0_P
AK22 DDR3_B_DQS1_N 27 DQS1_N
AJ22 DDR3_B_DQS1_P 29 DQS1_P
AU21 DDR3_B_DQS2_N 45 DQS2_N
AT21 DDR3_B_DQS2_P 47 DQS2_P
BB22 DDR3_B_DQS3_N 62 DQS3_N
BA22 DDR3_B_DQS3_P 64 DQS3_P
BA14 DDR3_B_DQS4_N 135 DQS4_N
BA15 DDR3_B_DQS4_P 137 DQS4_P
AR12 DDR3_B_DQS5_N 152 DQS5_N
AP12 DDR3_B_DQS5_P 154 DQS5_P
AL14 DDR3_B_DQS6_N 169 DQS6_N
AK15 DDR3_B_DQS6_P 171 DQS6_P
AN14 DDR3_B_DQS7_N 186 DQS7_N
AN15 DDR3_B_DQS7_P 188 DQS7_P
AU17 DDR3_B_CLK0_N 101 CK0_P
AT17 DDR3_B_CLK0_P 103 CK0_N
AV18 DDR3_B_CLK1_N 102 CK1_P
Table 1-5: DDR3 SODIMM Socket J3 Connections to the FPGA (Cont’d)
XCVX690T (U1) Pin Net Name
SODIMM Memory J3
Pin Number Pin Name
