Xilinx VC709 User Manual

VC709 Evaluation Board www.xilinx.com 51
UG887 (v1.0) February 4, 2013
Feature Descriptions
C2 FMC1_HPC_DP0_C2M_P E2 D1 PWRCTL1_VCC4B_PG AL32
C3 FMC1_HPC_DP0_C2M_N E1 D4 FMC1_HPC_GBTCLK0_M2C_P G10
C6 FMC1_HPC_DP0_M2C_P D8 D5 FMC1_HPC_GBTCLK0_M2C_N G9
C7 FMC1_HPC_DP0_M2C_N D7 D8 FMC1_HPC_LA01_CC_P J40
C10 FMC1_HPC_LA06_P K42 D9 FMC1_HPC_LA01_CC_N J41
C11 FMC1_HPC_LA06_N J42 D11 FMC1_HPC_LA05_P M41
C14 FMC1_HPC_LA10_P N38 D12 FMC1_HPC_LA05_N L41
C15 FMC1_HPC_LA10_N M39 D14 FMC1_HPC_LA09_P R42
C18 FMC1_HPC_LA14_P N39 D15 FMC1_HPC_LA09_N P42
C19 FMC1_HPC_LA14_N N40 D17 FMC1_HPC_LA13_P H39
C22 FMC1_HPC_LA18_CC_P M32 D18 FMC1_HPC_LA13_N G39
C23 FMC1_HPC_LA18_CC_N L32 D20 FMC1_HPC_LA17_CC_P L31
C26 FMC1_HPC_LA27_P J31 D21 FMC1_HPC_LA17_CC_N K32
C27 FMC1_HPC_LA27_N H31 D23 FMC1_HPC_LA23_P P30
C30 FMC1_HPC_IIC_SCL U52.4 D24 FMC1_HPC_LA23_N N31
C31 FMC1_HPC_IIC_SDA U52.3 D26 FMC1_HPC_LA26_P J30
C34 GND NA D27 FMC1_HPC_LA26_N H30
C35 VCC12_P NA D29 FMC1_HPC_TCK_BUF U19.14
C37 VCC12_P NA D30 FMC1_TDI_BUF U19.18
C39 VCC3V3 NA D31 FMC1_TDO_FPGA_TDI T10
D32 VCC3V3 NA
D33 FMC1_HPC_TMS_BUF U19.17
D34 NC NA
D35 GND NA
D36 VCC3V3 NA
D38 VCC3V3 NA
D40 VCC3V3 NA
E2 FMC1_HPC_HA01_CC_P D35 F1 FMC1_HPC_PG_M2C AN34
E3 FMC1_HPC_HA01_CC_N D36 F4 FMC1_HPC_HA00_CC_P E34
E6 FMC1_HPC_HA05_P G32 F5 FMC1_HPC_HA00_CC_N E35
Table 1-20: VITA 57.1 FMC HPC J35 Connections to FPGA U1 (Cont’d)
J35 FMC
HPC Pin
Schematic Net Name U1 FPGA Pin
J64 FMC
HPC Pin
Schematic Net Name
U1 FPGA
Pin
