Xilinx VC709 User Manual

VC709 Evaluation Board www.xilinx.com 53
UG887 (v1.0) February 4, 2013
Feature Descriptions
G15 FMC1_HPC_LA12_P R40 H13 FMC1_HPC_LA07_P G41
G16 FMC1_HPC_LA12_N P40 H14 FMC1_HPC_LA07_N G42
G18 FMC1_HPC_LA16_P K37 H16 FMC1_HPC_LA11_P F40
G19 FMC1_HPC_LA16_N K38 H17 FMC1_HPC_LA11_N F41
G21 FMC1_HPC_LA20_P Y29 H19 FMC1_HPC_LA15_P M36
G22 FMC1_HPC_LA20_N Y30 H20 FMC1_HPC_LA15_N L37
G24 FMC1_HPC_LA22_P R28 H22 FMC1_HPC_LA19_P W30
G25 FMC1_HPC_LA22_N P28 H23 FMC1_HPC_LA19_N W31
G27 FMC1_HPC_LA25_P K29 H25 FMC1_HPC_LA21_P N28
G28 FMC1_HPC_LA25_N K30 H26 FMC1_HPC_LA21_N N29
G30 FMC1_HPC_LA29_P T29 H28 FMC1_HPC_LA24_P R30
G31 FMC1_HPC_LA29_N W30 H29 FMC1_HPC_LA24_N P31
G33 FMC1_HPC_LA31_P M28 H31 FMC1_HPC_LA28_P L29
G34 FMC1_HPC_LA31_N M29 H32 FMC1_HPC_LA28_N L30
G36 FMC1_HPC_LA33_P U31 H34 FMC1_HPC_LA30_P V30
G37 FMC1_HPC_LA33_N T31 H35 FMC1_HPC_LA30_N V31
G39 VCC1V8 NA H37 FMC1_HPC_LA32_P V29
H38 FMC1_HPC_LA32_N U29
H40 VCC1V8 NA
J2 NC NA K1 NC NA
J3 NC NA K4 NC NA
J6 FMC1_HPC_HA03_P H33 K5 NC NA
J7 FMC1_HPC_HA03_N G33 K7 FMC1_HPC_HA02_P E33
J9 FMC1_HPC_HA07_P C38 K8 FMC1_HPC_HA02_N D33
J10 FMC1_HPC_HA07_N C39 K10 FMC1_HPC_HA06_P G36
J12 FMC1_HPC_HA11_P H33 K11 FMC1_HPC_HA06_N G37
J13 FMC1_HPC_HA11_N G33 K13 FMC1_HPC_HA10_P H38
J15 FMC1_HPC_HA14_P E37 K14 FMC1_HPC_HA10_N G38
J16 FMC1_HPC_HA14_N E38 K16 FMC1_HPC_HA17_CC_P C35
J18 FMC1_HPC_HA18_P F39 K17 FMC1_HPC_HA17_CC_N C36
J19 FMC1_HPC_HA18_N E39 K19 FMC1_HPC_HA21_P D37
Table 1-20: VITA 57.1 FMC HPC J35 Connections to FPGA U1 (Cont’d)
J35 FMC
HPC Pin
Schematic Net Name U1 FPGA Pin
J64 FMC
HPC Pin
Schematic Net Name
U1 FPGA
Pin
