Chapter 5: Miscellaneous Functions
R
Table 5-6: Ethernet MAC Register Addresses
{HOSTEMAC1SEL, HOSTADDR[9:0]} Register Description
EMAC0
0x200 Receiver Configuration (Word 0)
0x240 Receiver Configuration (Word 1)
0x280 Transmitter Configuration
0x2C0 Flow Control Configuration
0x300 Ethernet MAC Mode Configuration
0x320 RGMII/SGMII Configuration
0x340 Management Configuration
0x380 Unicast Address (Word 0)
0x384 Unicast Address (Word 1)
0x388 Multicast Address Table Access (Word 0)
0x38C Multicast Address Table Access (Word 1)
0x390 Address Filter Mode
EMAC1
0x600 Receiver Configuration (Word 0)
0x640 Receiver Configuration (Word 1)
0x680 Transmitter Configuration
0x6C0 Flow Control Configuration
0x700 Ethernet MAC Mode Configuration
0x720 RGMII/SGMII Configuration
0x740 Management Configuration
0x780 Unicast Address (Word 0)
0x784 Unicast Address (Word 1)
0x788 Multicast Address Table Access (Word 0)
0x78C Multicast Address Table Access (Word 1)
0x790 Address Filter Mode
Notes:
1. HOSTEMAC1SEL acts as address bit 10 to select between EMAC0 and EMAC1.
