ZC702 Board User Guide www.xilinx.com 35
UG850 (v1.7) March 27, 2019
Feature Descriptions
Table 1-16 lists the USB connections between the XC7Z020 SoC PS Bank 501 and the
CP2103 UART bridge.
Refer to the Silicon Labs website for technical information on the CP2103GM and the VCP
drivers [Ref 19].
HDMI Video Output
[Figure 1-2, callout 13]
The ZC702 board provides a high-definition multimedia interface (HDMI®) video output
using an Analog Devices ADV7511KSTZ-P HDMI transmitter at U40. The HDMI output is
provided on a Molex 500254-1927 HDMI type-A receptacle at P1. The ADV7511 supports
1080P 60Hz, YCbCr 4:2:2 encoding via 16-bit input data mapping.
The ZC702 board supports the following HDMI device interfaces:
• 16 data lines
•Independent VSYNC, HSYNC
• Single-ended input CLK
• Interrupt Out pin to XC7Z020 SoC
•I2C
•SPDIF
Table 1-16: XC7Z020 SoC to CP2103 Connections
XC7Z020 SoC (U1) Bank 500
Net Name
CP2103GM Device (U36)
Pin Name Pin Number Function Direction Pin Function Direction
PS_MIO48 D11 TX Data Out USB_UART_RX 24 RXD Data In
PS_MIO49 C14 RX Data In USB_UART_TX 25 TXD Data Out
