ZC702 Board User Guide www.xilinx.com 55
UG850 (v1.7) March 27, 2019
Feature Descriptions
C14 FMC1_LPC_LA10_P LVCMOS25 L17 D12 FMC1_LPC_LA05_N LVCMOS25 N18
C15 FMC1_LPC_LA10_N LVCMOS25 M17 D14 FMC1_LPC_LA09_P LVCMOS25 M15
C18 FMC1_LPC_LA14_P LVCMOS25 J16 D15 FMC1_LPC_LA09_N LVCMOS25 M16
C19 FMC1_LPC_LA14_N LVCMOS25 J17 D17 FMC1_LPC_LA13_P LVCMOS25 P16
C22 FMC1_LPC_LA18_CC_P LVCMOS25 D20 D18 FMC1_LPC_LA13_N LVCMOS25 R16
C23 FMC1_LPC_LA18_CC_N LVCMOS25 C20 D20 FMC1_LPC_LA17_CC_P LVCMOS25 B19
C26 FMC1_LPC_LA27_P LVCMOS25 C17 D21 FMC1_LPC_LA17_CC_N LVCMOS25 B20
C27 FMC1_LPC_LA27_N LVCMOS25 C18 D23 FMC1_LPC_LA23_P LVCMOS25 G15
C30 FMC1_LPC_IIC_SCL D24 FMC1_LPC_LA23_N LVCMOS25 G16
C31 FMC1_LPC_IIC_SDA D26 FMC1_LPC_LA26_P LVCMOS25 F18
C34 GA0 = 0 = GND D27 FMC1_LPC_LA26_N LVCMOS25 E18
C35 VCC12_P D29 FMC1_LPC_TCK_BUF
C37 VCC12_P D30 FMC_TDI_BUF
C39 VCC3V3 D31
FMC1_LPC_TDO_FMC2_L
PC_TDI
D32 VCC3V3
D33 FMC1_LPC_TMS_BUF
D34 NC
D35 GA0 = 0 = GND
D36 VCC3V3
D38 VCC3V3
D40 VCC3V3
G2
FMC1_LPC_CLK1_M2C_
P
LVCMOS25 M19 H1 NC
G3
FMC1_LPC_CLK1_M2C_
N
LVCMOS25 M20 H2
FMC1_LPC_PRSNT_M2C_
B
G6 FMC1_LPC_LA00_CC_P LVCMOS25 K19 H4 FMC1_LPC_CLK0_M2C_P LVCMOS25 L18
G7 FMC1_LPC_LA00_CC_N LVCMOS25 K20 H5 FMC1_LPC_CLK0_M2C_N LVCMOS25 L19
G9 FMC1_LPC_LA03_P LVCMOS25 J20 H7 FMC1_LPC_LA02_P LVCMOS25 L21
G10 FMC1_LPC_LA03_N LVCMOS25 K21 H8 FMC1_LPC_LA02_N LVCMOS25 L22
G12 FMC1_LPC_LA08_P LVCMOS25 J21 H10 FMC1_LPC_LA04_P LVCMOS25 M21
G13 FMC1_LPC_LA08_N LVCMOS25 J22 H11 FMC1_LPC_LA04_N LVCMOS25 M22
G15 FMC1_LPC_LA12_P LVCMOS25 N22 H13 FMC1_LPC_LA07_P LVCMOS25 J15
G16 FMC1_LPC_LA12_N LVCMOS25 P22 H14 FMC1_LPC_LA07_N LVCMOS25 K15
G18 FMC1_LPC_LA16_P LVCMOS25 N15 H16 FMC1_LPC_LA11_P LVCMOS25 R20
Table 1-28: LPC Connections, FMC1 (J3) to XC7Z020 SoC U1 (Cont ’d)
FMC1
J3 Pin
Net Name
I/O
Standard
XC7Z020
(U1) Pin
FMC1
J3 Pin
Net Name
I/O
Standard
XC7Z020
(U1) Pin
