ZC70
2 Board User
Guide
www
.xilinx.com
60
UG850 (v1.7) Mar
ch 27, 2019
Fea
ture Descriptions
X-Ref Targ
et - Figure 1-2
9
Figure 1-29:
Onboard Power Regulator
s
VCCPINT
VCCA
UX
VCCP
A
UX
VCCADJ
VCC1V5
VCCBRAM
J60
12 V
VCCMIO
VCCINT
VCC3V3
VCC2V5
P
ower Controller 2 (A
ux)
PMBus Addr 0b0110101
Switching Regulator
1.5V at 10A
U19
Switching Regulator
2.5V at 10A
Switching Regulator
1.0V at 10A
U20
Switching Regulator
1.8V at 10A
U33
P
ower Controller 3
PMBus Addr 0b0110110
Switching Regulator
2.5V at 10A
U21
Switching Regulator
3.3V at 10A
U34
VTTDDR
U32
P
ower Controller 1 (Core)
PMBus Addr 0b0110100
Switching Regulator
1.8V at 10A
U18
Switching Regulator
1.8V at 10A
Switching Regulator
1.0V at 10A
U17
Switching Regulator
1.0V at 10A
UG850_c1_29
_090215
Linear Regulator
0.75V at 3A
U22
VREF
S
e
n
d
F
e
e
d
b
a
c
k
59
61
