o Characteristics of Device Installation Location
The table below shows the minimum characteristics of the installation location for the stable
and reliable operation of the device.
Note that non-observance of the following points will cause the device to function incorrectly
and possible consequences are beyond the responsibility of the company.
Above 40 ° C, for every 1 degree of Celsius increase,
consider 2% reduction in the output power
For every 100 meters above 1000 meters, consider
about 2% decrease in the rated power
Table 5: The device's physical installation characteristics
o Motor
Before installing the device, remove the motor from the mechanical system, if possible. This is
especially important where turning the motor in the reverse direction causes damages to the
system.
Connect the motor case to the ground. Otherwise, in the case of a connection of the motor case
to the coil, there is a possibility of extreme electrical injury and even death.
If the metal is used in the entire system and the body of the motor is connected to the system,
you can connect any point of the system to the ground.
The motor power should never be larger than the rated power of the inverter. Otherwise, the
device performance is not optimal and the warranty is invalidated.
o Mechanical Installation
To install the remote control device inside the desired control panel, and according to the
conditions described in the installation location section, firstly mark the drilling spot in
alignment by the stencil (which is available with the device) and drill this spot using drill-3. Then,
close the screws of the top of the device (6 screws of diameter 4 are available with the device)
