Faults
If a fault occurs for the device, the output of the device will be quickly disconnected and the
corresponding fault message will be displayed.
There are 3 ways to reset the fault state:
1 - Pressing the Reset key to reset the fault after 5 seconds.
2 - Disabling the Enable command
3 - Stopping the inverter (In the case of a fault occurrence during the device operation).
Note that the voltage-deficiency, the device heat-sink temperature, or the short-circuit faults
may not be capable of being reset until the problem is resolved. In this case, the conditions must
first return to the normal state until the fault can be reset .
If a fault occurs frequently, avoid resetting it and contact the company's advisers to resolve the
issue.
Each fault (except the short-circuit) resets after 3 seconds, and after 10 times of the inverter
auto-reset, it will fail with each fault, and it will reset again 30 seconds later.
Possible Cause
Fault Code
Fault
Number
- Short circuit in outputs
- Failure of power section

Short Circuit
1
If disconnecting the output wires did not fix the fault,
the device might be damaged.
- High load
- Excessive acceleration
- Motor failure
- Incorrect setting of the motor
parameters
- High value of  parameter

Over Current
2
Check the items.
If disconnecting the motor did not fix the fault, the
device might be damaged.
- High startup acceleration ()

Over Current in
Acceleration
3
Decreasing the startup acceleration or 
- High deceleration ()
- Low value of the brake resistance or
its short circuit

Over Current in
Deceleration
4
Decreasing the deceleration or 
Checking the brake resistance
- High deceleration ()
- Low value of the brake resistance or
its short circuit

Over Voltage during
Deceleration
5
Decreasing the deceleration or 
Checking the brake resistance
