Xima L100 - Inputs and Outputs Parameters; System Parameters

56
Parameter
Name
Setting Range
Default Value
Type

Low-Speed Gain
0.50-1.20
1.00
R/W

Motor Power
1.0-7.5 kW
7.5
R/W

Motor Pole pairs
1-50
2
R/W

Motor RPM
30-9999 RPM
1460
R/W

Motor Power Factor
0.20-0.90
0.50
R/W
o Inputs and Outputs Parameters
Parameter
Name
Setting Range
Default Value
Type

Speed Input
Method
0-3
0
R/W

Relay 1 Setting
0-8
0
R/W

Relay 2 Setting
0-8
1
R/W

Relay 3 Setting
0-8
2
R/W

OP 2 Setting
0-8
3
R/W

Door Speed
0.00-2.50 m/s
0.20
R/W

Digital Input
Configuration
0-8
7
R/W

Multi Speed 1
0.00-2.50 m/s
0.12
R/W

Multi Speed 2
0.00-2.50 m/s
0.20
R/W

Multi Speed 3
0.00-2.50 m/s
0.30
R/W

Multi Speed 4
0.00-2.50 m/s
0.50
R/W

Multi Speed 5
0.00-2.50 m/s
0.70
R/W

Multi Speed 6
0.00-2.50 m/s
0.80
R/W

Multi Speed 7
0.00-2.50 m/s
1.00
R/W

Rescue Time 1
0-100 s
5
R/W

Rescue Time 2
1-1000 s
200
R/W
o System Parameters
Parameter
Name
Setting Range
Default Value
Type

Password
0-9999
0
R/W

Restore/Back-up
0-4
0
R/W

Rescue Mode
0-4
3
R/W

UPS Power / Rescue
Power
0.2-20.0 kW
2.0/0.5
R/W

Switching Frequency
3.0-10.0 KHz
6.0
R/W

Rescue Search Time
1.0-5.0 s
2.0
R/W

Version of software
0-9900
1000
R/O
