Monitoring Functions
When the inverter is functioning normally, you can see the various output parameters of the inverter
by pressing Up or Down.
Changes of the Screen and LEDs
Output frequency of the device in Hertz
(dot and Hz/RPM light will turn on)
Output current from 0.00 to 20.00 Amps.
(The second dot and A/% light will turn on)
Motor speed in meters per second
(the dot will turn off and Hz/RPM light will
turn on)
Output power in kilowatts.
( will be displayed on the left of the
screen)
Power Capacitor Voltage of the device.
( will be displayed on the left of the
screen)
Internal heat sink temperature
( will be displayed on the left of the
screen)
