Xinje DS2 series Manual

32
P0-04.1
Data bit
0
0：8
P0-04.2
Stop bit
2
0：2 bits；2：1 bit
P0-04.3
Parity bit
2
0～2
0：no parity 1：odd parity 2：even parity
Modbus station no. can be set through P0-03.
Parameter
Function
Unit
Default setting
Range
P0-03
Modbus station no.
－
1
1～255
Note: the above parameters will be worked after re-power on.
7. Regeneration resistor
Servo motor type
Internal
regeneration resistor
External regeneration resistor
DS2-20P2-AS/AS6
DS2-20P4-BS/BS6
No internal
regeneration resistor
The external regeneration resistor
specification: 40Ω~50Ω 100W, connect
it to the terminal P+ and PB of servo
motor drive, not supply when out of
factory, need purchase.
DS2-20P4-AS/AS6
DS2-20P7-AS/AS6
No internal
regeneration resistor
The external resistor specification: 100Ω
100W. Connect it to the terminal P+ and
PB of servo motor drive. There are silver
and aluminum cover resistor in the
packaging. No difference between
positive and negative when wiring.
