Xinje DS2 series Manual

33
DS2-20P7-BSW/BSW6
DS2-21P5-AS/AS6
DS2-21P5-AS2
DS2-41P5-AS/AS6
The internal resistor
specification is
100Ω100W, short
connect the terminal P
+ and D(already short
connected when out of
factory), disconnect
P+ and C. Set
P0-10=0
Connect the regeneration resistor to
terminal P+ and C. At the same time, tear
the short jumper between P+ and D. The
external resistor specification is from
40Ω to 50Ω, rated power is from 200W
to 400W. Regeneration resistor need to
purchase. The factory doesn’t supply it.
Set P0-10=1.
DS2-22P3-AS/AS6
DS2-43P0-AS/AS6
The internal resistor
specification is
75Ω/200W, short
circuit the terminal P +
and D(already short
connected when out of
factory), disconnect
P+ and C. Set
P0-10=0
Connect the regeneration resistor to
terminal P+ and C. At the same time, tear
down the short jumper between P+ and
D .The internal resistor specification is
from 40Ω to 50Ω, rated power is from
300W to 500W. The regeneration resistor
need to purchase .The factory doesn’t
supply it. Set P0-10=1.
Note:
For the drive with internal regeneration resistor, if it needs to use external regeneration
resistor, you have to modify the drive’s parameters again. Or the drive will work abnormal.
Even worse, it will cause huge damage to the drive.
Parameter setting: P0-10=1 for external regeneration resistor;
P0-10=0 for internal regeneration resistor. If there is internal regeneration resistor, you need
to modify the parameter ,if not ,you don’t need to modify the parameter.
