Xinje DS2 series Manual

8
Electrical time constant（ms）
3.46
3.33
5.57
4.00
Weight （Kg）
11.5
11.4
20.5
17.1
Encode line number（PPR）
2500
Pole number
4
Motor insulation level
Class B（130℃）
Protection level
IP65
Use condition
Environment
temperature
－20℃～＋50℃
Environment
humidity
Under 90% RH(no condensation)
(2) servo drive
Servo element
DS2 series 220V
DS2 series 380V
Suitable encoder
Incremental encoder （2500 ppr）
Input power
DS2-2□P□-□: single/three phases AC200～240V,
50/60Hz
DS2-4□P□-□: three-phases AC380～400V, 50/60Hz
【note：DS2-2□P□-□:
Under 1.5KW（not including 1.5KW）may use three
phases AC200～240V 50/60Hz;
Above 1.5KW（including 1.5KW）suggest use three
phases AC200～240V 50/60Hz
Control mode
Three phases full wave rectification IGBT PWM
control, sine current drive mode
Use
Temperature
0～+50 ℃/-20～+85 ℃

Xinje DS2 series Specifications

General

Brand	Xinje
Model	DS2 series
Category	Servo Drives
Language	English
