Xinje DS2 series Manual

26
.
L
N
.
U
V
W
P+
D
C
P-
.
 DS2-20P7-BSW/BSW6
Terminal
Function
Explanation
L/N
Power input of main
circuit
AC single-phase 200 ～240V,
50/60Hz
●
Empty Pin
U, V, W
Motor terminal
Connect to the motor
P+, D, C
Use internal
regeneration resistor
Short connect the terminal P+
and D , disconnect P+ and C;
Set P0-10=0
Use external
regeneration resistor
Connect regeneration resistor to
terminal P+ and C, cut down the
short wires between P+ and D;
set P0-10=1
P+/P-
Bus terminal
Can measure the real-time voltage
of bus , be careful it is
dangerous
2. Winding connector of servo motor
Signal
60, 80, 90 series motor
110,130,180 series
motor
U
1-brown(red)
2-brown
V
3-black(blue)
3-black
W
2-blue(yellow))
4-blue
PE
4-yellow and green(yellow and
green)
1-yellow and green
