Xinje DS2 series Manual

52
limit input.
2: undefined.
3: P-CL, N-CL is ON, T-REF is
external torque limit input.
08
V-REF distribution
0: undefined.
1: V-REF external speed limit
input.
-
0
0、1
○
1, 2
09
Forced input terminal
0: undefined.
1: SO1 output signal
2: SO2 output signal
3: SO3 output signal
-
0
0-3
√
All
10
Regenerative resistor choice
0: internal regenerative resistor
1: external regenerative resistor
-
0
0, 1
●
All
20
Running time
-
0
Monitor value, cannot be changed
21
Alarm times
-
0
Monitor value, cannot be changed
2. Control parameter P1 (address: 0100～01FF)
P1-
Name
Unit
Default
value
Range
Effective
time
Suitable
mode
00
Speed loop gain
1Hz
100
1～5000
√
All
01
Speed loop integral time
0.1
ms
400
1～
50000
√
All
02
Position loop gain
1/s
100
1～2000
√
5, 6
03
Reserved
